Approval planning of Flood protection, Solingen-Unterburg, Germany
Project description:
Solingen Unterburg, flood protection of Eschbach, deepening of the river-bed, new construction of embankments, bridges and underpinnings of retaining walls, bridges and buildings in Solingen Unterburg, Eschbach, Update hydraulic model.Services:
- HOAI Facility Planning of Structures and Structural Design Phases 1-4 (approval planning for a plan approval procedure acc. WHG)
- Surveying, preparation DGM (Digital elevation Model) foreland and river tubing
- Water level calculations
- Site investigations, investigation of existing structures
- Project presentations for public agencies (TÖB), residents, citizens and project participants
Additional project data:
- Bottom width of water from 4.80 m to 6.50 m, depth to 3.0 m
- Full board flood runoff 37.0 m³/s
- Up to 1.6 m lowering of the river bed approx. 500 m
- Partial profile expansion up to 1.0 m
- New construction, underpinning of left and right bank walls over a length of approx. 650 m
- New construction, underpinning of 9 bridge structures
- Fish upstream migration installation by a ‘Raugerinne Basin pass’
At a glance:
Images:
